1.?The machine is extremely user-friendly and can rapidly generate a large quantity of copper wire, significantly enhancing production efficiency.
2.?The machine is equipped with a high-precision control system. This enables it to produce top-quality copper wire, effectively meeting the diverse requirements of customers.
3.?The machine is compact in size, making it adaptable to the space constraints of numerous factories.
4.?The application of environmentally friendly paint not only endows the machine with an attractive appearance but also aligns with sustainable manufacturing principles.
| Model: | 22DTA |
| Inlet diameter: | 1.6mm |
| Outlet diameter: | 0.15-0.6mm |
| Quantity of drawing dies: | 22 |
| Slip ratio of main machine: | 15% |
| Slip ratio of last die: | 8% |
| Max. Drawing speed: | 2000m/min |
| Using motor/ main motor: | 18.5kw |
| Usage: | Bare copper wire drawing |
| Correction system: | Automatically control |
| Annealing method: | DC three section annealing |
| Voltage: | 380V or Customized |
| Brake: | Pneumatic brake |
| Colour: | As customer's need |
| Brand: | Liqiang or OEM |
| Operation direction: | Right hand machine |
