1.?The design features an extended production headcount of 40 heads, which effectively boosts production yield and efficiency.
2.?For the tinning process, the machine can be equipped with either tungsten-steel dies or diamond dies.
3.?The annealing furnace is equipped with a heat - heat-preservation device, which is designed to maintain an even temperature and save power.
4.?The leading roller is equipped with an independent variable-speed motor, enabling step-less speed adjustment.
5.?The 40-head take-up machine has a two-layer (top and bottom) structure. It has a smaller volume and saves space. Moreover, it is equipped with two independent traversing units, allowing for the simultaneous winding of tinned wires of different sizes.
| Model: | 40H |
| Inlet diameter: | 0.1-0.6mm |
| Max inlet wire: | 40 |
| Speed: | 300m/min |
| Payoff bobbin model: | 300 |
| Anealing furnace length: | 3.5-6.0m |
| Annealing method: | tube annealing |
| Tinned method: | hot dip |
| Payoff method: | brush payoff |
| Take-up motor: | Double speed torque motor |
| Voltage: | 380V or Customized |
| Colour: | As customer's need |
| Brand: | Liqiang or OEM |
| Production size: | 21000LX2200Wx1800H |
| Operation direction: | Right hand machine |
| Delivery Time: | 30-60 Days |
