1.?The tower wheels are designed with a double-layer arrangement, which efficiently saves space and optimizes the overall spatial layout of the equipment.
2.?The winding shaft makes use of dual-frequency conversion synchronous control, leading to substantial energy savings and promoting more sustainable operation.
3.?With the zero-slip pilot design, the machine attains high productivity and consistently manufactures finished wires of top-notch quality.
4.?The electrical control system is equipped with an automatic memory function. This function ensures that during normal start-stop operations and restarts following a shutdown, no manual intervention is needed, and the machine can smoothly accelerate its operation.
| Model: | 24DT |
| Inlet diameter: | 0.6-1.2mm |
| Outlet diameter: | 0.1-0.3mm |
| Quantity of drawing dies: | 24 |
| Max. Drawing speed: | 2000m/min |
| Slip ratio of main machine: | 13% |
| Slip ratio of last die: | 8% |
| Using motor/ main motor: | 15KW |
| Usage: | Bare copper wire drawing |
| Correction system: | Automatically control |
| Annealing method: | DC three section annealing |
| Voltage: | 380V or Customized |
| Colour: | As customer's need |
| Brand: | Liqiang or OEM |
| Brake: | Pneumatic brake |
| Operation direction: | Right hand machine |
