1.?The machine adopts new technology and features an integral cast-iron box, presenting a more exquisite appearance.
2.?It is equipped with high-precision grinding gears and Japanese NSK or NTN bearings, which effectively enhance the operating accuracy and extend the service life of the machine.
3.?With a single-drum arrangement, rapid die-change system, oil-immersed wire lubrication, and horizontal annealing device, it is easy to operate and ensures the quality of the wire.
4.?It has a fast reaction speed and stable working performance.
5.?Through fully - immersed lubrication cooling, the quality of the wire is guaranteed.
| Model: | LHD450-13DT |
| Inlet diameter: | Φ8.0mm |
| Outlet diameter: | Φ1.2 mm ~Φ4.5mm |
| Max. annealing speed: | 25m/s |
| Drawing motor: | 280KW DC |
| Final capstan motor: | 75KW DC |
| Diameter of drum: | Φ450mm? |
| Take up bobbin: | PND500/630 |
| Max. drawing dies: | 13 |
| Max. length of wire accumulator: | 7m |
| Annealing voltage: | 60V |
| Annealing current: | 6000A |
| Motor for double spooler: | 30KW*2 |
| Motor for coiler: | 22KW |
| Max. size of drawing dies: | Φ53*35 |
| Installation power: | 510KW |
