1. The wire drawing machine has dual functions, which can synchronously achieve wire drawing operation and annealing treatment of copper wire.
2. This wire drawing machine can simultaneously carry out wire drawing or annealing processes on copper wires.
When the multi-wire series drawing machine is running, the wire will not deviate and the drawing direction is horizontal.
4. With an independent tension control system, the wire is less prone to breakage during processing.
5. There are two winding modes available for flexible selection, and the output wire can be wound on the same spool or separately wound on four spools.
6. Use environmentally friendly paint to ensure that the appearance of the machine is bright in color, has good glossiness, and meets the standard for surface smoothness.
|
Type |
WDF450/13-2 |
WDF450-11-2 |
WDF450-9-2 |
|
Suit for |
Cu |
||
|
No.of wire |
2 |
2 |
2 |
|
Max.dies |
13X2 |
11X2 |
9X2 |
|
Inlet dia.(mm) |
8 |
8 |
8 |
|
Outlet dia.(mm) |
2X 1.2-3.5 ???????????????????????????1X 1.2-4.5 |
2X 1.5-3.5 ?????????????????????????????1X 1.5-4.5 |
2X 2.0-3.5 ????????????????????????????????1X 2.0-4.5 |
|
Max.speed(mpm) |
1800 |
1500 |
1200 |
|
Draw wheel(mm) |
450 |
450 |
450 |
|
Drive method |
Variable frequency motor /AC servo /Direct drive motor |
||
|
Type |
WDF450/13-2 |
WDF450-11-2 |
WDF450-9-2 |
|
Suit for |
Cu |
||
|
No.of wire |
1 |
1 |
1 |
|
Max. dies |
13 |
11 |
9 |
|
Inlet dia.(mm) |
8 |
8 |
8 |
|
Outlet dia.(mm) |
?1.2-4.5 |
1.5-4.5 |
2.0-4.5 |
|
Max.speed(mpm) |
1800 |
1500 |
1200 |
|
Draw wheel(mm) |
450 |
450 |
450 |
|
Drive method |
Variable frequency motor /AC servo /Direct drive motor |
||
