1.?This wire drawing machine has multiple functions, including simultaneous wire drawing and annealing of copper wires.
2. The wire drawing machine has powerful performance and can simultaneously perform wire drawing operations on 16 copper wires.
3. With the independent tension control system, the force on the wire during processing can be precisely controlled, making it less prone to breakage.
4. The machine adopts environmentally friendly paint, effectively ensuring its long-lasting bright color, good glossiness, and excellent surface smoothness.
|
Type |
DT100.140.8-25 |
DT120.200.14-19 |
DT100.140.16-25 |
|
No.of wire |
8 |
14 |
16 |
|
Inlet dia.(mm) |
1.4-1.8 |
Max.2.6 |
1.5-1.8 |
|
Outlet dia.(mm) |
0.12-0.64 |
0.25-0.64 |
0.12-0.4 |
|
Max.speed(mpm) |
1800 |
1800 |
1800 |
|
Max.dies |
25 |
19 |
25 |
|
Main motor(kw) |
110KW+37KW |
85KW+200KW+55KW |
180KW+45KW |
|
Draw wheel(mm) |
100 |
120 |
100 |
|
Annealing control |
?DC |
||
|
Contact wheel dia.(mm) |
140 |
200 |
140 |
|
Annealing voltage (V) |
60V |
||
|
Annealing current (A) |
2000 |
5000 |
2000 |
|
Type |
DT120.200.16-19 |
DT120.200.20-19 |
DT100.200.24-25 |
|
No.of wire |
16 |
20 |
24 |
|
Inlet dia.(mm) |
1.8-2.6 |
1.8-2.6 |
1.8-2.0 |
|
Outlet dia.(mm) |
0.25-0.80 |
0.2-0.64 |
1.5-0.4 |
|
Max.speed(mpm) |
1800 |
1800 |
1800 |
|
Max.dies |
19 |
19 |
25 |
|
Main motor(kw) |
85KW+200KW+55KW |
110KW+200KW+75KW |
85KW+250KW+55KW |
|
Draw wheel(mm) |
120 |
120 |
100 |
|
Annealing control |
DC |
||
|
Contact wheel dia.(mm) |
200 |
200 |
200 |
|
Annealing voltage (V) |
60V |
||
|
Annealing current (A) |
5000 |
6000 |
5000 |
