1.?Machine structure: Formed by one-piece welding.
2.?Electric control parts are sourced from top-class domestic or overseas brands.
3.?Main pedestal: Welded with A3 steel plates, and the mating parts are precisely milled to ensure the machine's precision.
4.?The high-density carbon brush features a long service life.
| Model: | 17DCT |
| Usage: | Bare copper wire drawing |
| Inlet diameter: | Φ3.0mm-Φ3.5mm |
| Outlet diameter: | Φ0.8-2.8mm Or Φ0.5-2.0mm |
| Quantity of drawing dies: | 17 |
| Slip ratio of main machine: | 18% |
| Slip ratio of last die: | 12.50% |
| Correction system: | Automatically control |
| Max. Drawing speed: | 20m/s |
| Using motor/ main motor: | 45KW |
| Dynamic control: | Double frequency converters control |
| Operation direction: | Right hand machine |
| (from Left to right) | |
| Colour: | As customer's need |
| Brand: | Liqiang or OEM |
| Voltage: | 380V or Customized |
| Brake: | Pneumatic brake |
