1. Multi wire series drawing machine, drawing without deflection, horizontal drawing
2. By using a tension rod, the winding speed is synchronized with the drawing and annealing speeds, effectively reducing the occurrence of wire breakage
3. The wire receiving device adopts a shaft frame of a pneumatic lifting platform and is manually operated
4. By adjusting the transformer and rectifier, it can be adjusted through a program
5. The equipment is sprayed with environmentally friendly paint
|
Type |
DT100.140.8-25 |
DT120.200.14-19 |
DT100.140.16-25 |
|
No.of wire |
8 |
14 |
16 |
|
Inlet dia.(mm) |
1.4-1.8 |
Max.2.6 |
1.5-1.8 |
|
Outlet dia.(mm) |
0.12-0.64 |
0.25-0.64 |
0.12-0.4 |
|
Max.speed(mpm) |
1800 |
1800 |
1800 |
|
Max.dies |
25 |
19 |
25 |
|
Main motor(kw) |
110KW+37KW |
85KW+200KW+55KW |
180KW+45KW |
|
Draw wheel(mm) |
100 |
120 |
100 |
|
Annealing control |
?DC |
||
|
Contact wheel dia.(mm) |
140 |
200 |
140 |
|
Annealing voltage (V) |
60V |
||
|
Annealing current (A) |
2000 |
5000 |
2000 |
|
Type |
DT120.200.16-19 |
DT120.200.20-19 |
DT100.200.24-25 |
|
No.of wire |
16 |
20 |
24 |
|
Inlet dia.(mm) |
1.8-2.6 |
1.8-2.6 |
1.8-2.0 |
|
Outlet dia.(mm) |
0.25-0.80 |
0.2-0.64 |
1.5-0.4 |
|
Max.speed(mpm) |
1800 |
1800 |
1800 |
|
Max.dies |
19 |
19 |
25 |
|
Main motor(kw) |
85KW+200KW+55KW |
110KW+200KW+75KW |
85KW+250KW+55KW |
|
Draw wheel(mm) |
120 |
120 |
100 |
|
Annealing control |
DC |
||
|
Contact wheel dia.(mm) |
200 |
200 |
200 |
|
Annealing voltage (V) |
60V |
||
|
Annealing current (A) |
5000 |
6000 |
5000 |
