1.?The machine is equipped with double motors and double frequency converters, resulting in minimal slip.
2.?The machine has the function of detecting wire disorder and wire break during the input process.
3.?It is equipped with an automatic correction control system for coiling tension.
| Model: | B24/B |
| Quantity of drawing dies: | 24 |
| Inlet diameter: | Φ1.0-1.4mm |
| Outlet diameter: | Φ0.3-0.5mm |
| Max. Drawing speed: | 800m/min |
| Usage: | Bare copper wire drawing |
| Number of capstan: | 4 |
| Correction system: | Automatically control |
| Using motor/ main motor: | 15kw |
| Using motor/ take-up: | 3.7kw |
| Annealing method: | DC three section annealing |
| Brake: | Pneumatic brake |
| Voltage: | 380V or Customized |
| Brand: | Liqiang or OEM |
| Colour: | As customer's need |
| Operation direction: | Right hand machine |
