1.?With four drawing lines, the machine achieves higher efficiency.
2.?Thanks to the independent tension control, the wire is less likely to break.
3.?The use of imported electrical equipment ensures the machine operates more stably.
4.?Equipped with an imported PLC, it is easy to control the machine's running status.
| Model: | 20-4DT |
| Usage: | Bare copper wire drawing |
| Quantity of drawing dies: | 20 |
| Inlet diameter: | 4*Max.1.6mm |
| Outlet diameter: | 4*0.15mm-0.5mm |
| Slip ratio of main machine: | 15% |
| Slip ratio of last die: | 8% |
| Max. Drawing speed: | 1500m/min |
| Using motor/ main motor: | 37kw |
| Correction system: | Automatically control |
| Annealing method: | DC three section annealing |
| Voltage: | 380V or Customized |
| Brake: | Pneumatic brake |
| Brand: | Liqiang or OEM |
| Colour: | As customer's need |
| Operation direction: | Right hand machine |
