1.?It features a mature manufacturing process, a reasonable structure, stable operation, high-quality output, and high efficiency.
2.?It runs at a high speed and demonstrates excellent performance.
3.?The machine is painted with green paint, which makes it safer, and more reassuring, and gives it an attractive appearance.
4.?Equipped with a main-shaft meter counter, the machine can twist the same types of wires with a tolerance of only 0.01%.
| Model: | 650P |
| Max.rotating speed: | 2000RPM |
| Inlet wire dia.: | Φ0.18mm-Φ0.62mm |
| Twisting section: | 0.18mm2-6mm2 |
| Twisting interval: | 34(11.6mm-66.1mm) |
| Direction of twist: | S or Z adjustable |
| Take up spool: | Φ650*L475/max. |
| Reel top: | Φ50-Φ127 to be supplied as per spool size |
| Smooth rod rewinder: | Φ30mm |
| Main shaft center: | 850mm |
| Main shaft lubrication: | Thin oil lubrication |
| Main motor power: | 7.5KW |
| Machine dimension: | 3200L*1480W*1440H (mm) |
