1.?This wire drawing machine can simultaneously perform wire drawing operations or annealing treatment on copper wires.
2. The wire drawing machine can synchronize the wire drawing operation and annealing process of copper wire.
When the multi-wire series drawing machine is running, the wire will not deflect and always maintain a horizontal drawing direction.
4. With an independent tension control system, the wire is less prone to breakage during the processing.
5. The equipment adopts environmentally friendly paint, effectively ensuring bright color, good glossiness, and good surface smoothness of the machine appearance.
|
Type |
DT100.140.8-25 |
DT120.200.14-19 |
DT100.140.16-25 |
|
No.of wire |
8 |
14 |
16 |
|
Inlet dia.(mm) |
1.4-1.8 |
Max.2.6 |
1.5-1.8 |
|
Outlet dia.(mm) |
0.12-0.64 |
0.25-0.64 |
0.12-0.4 |
|
Max.speed(mpm) |
1800 |
1800 |
1800 |
|
Max.dies |
25 |
19 |
25 |
|
Main motor(kw) |
110KW+37KW |
85KW+200KW+55KW |
180KW+45KW |
|
Draw wheel(mm) |
100 |
120 |
100 |
|
Annealing control |
?DC |
||
|
Contact wheel dia.(mm) |
140 |
200 |
140 |
|
Annealing voltage (V) |
60V |
||
|
Annealing current (A) |
2000 |
5000 |
2000 |
|
Type |
DT120.200.16-19 |
DT120.200.20-19 |
DT100.200.24-25 |
|
No.of wire |
16 |
20 |
24 |
|
Inlet dia.(mm) |
1.8-2.6 |
1.8-2.6 |
1.8-2.0 |
|
Outlet dia.(mm) |
0.25-0.80 |
0.2-0.64 |
1.5-0.4 |
|
Max.speed(mpm) |
1800 |
1800 |
1800 |
|
Max.dies |
19 |
19 |
25 |
|
Main motor(kw) |
85KW+200KW+55KW |
110KW+200KW+75KW |
85KW+250KW+55KW |
|
Draw wheel(mm) |
120 |
120 |
100 |
|
Annealing control |
DC |
||
|
Contact wheel dia.(mm) |
200 |
200 |
200 |
|
Annealing voltage (V) |
60V |
||
|
Annealing current (A) |
5000 |
6000 |
5000 |
