1.?The medium wire drawing machine is able to draw two copper wires simultaneously.
2.?Operating at a high speed of 30m/s, the machine is energy-efficient and space-saving.
3.?The two-wire drawing design can reduce power consumption by 20 - 30% in comparison to two traditional single-wire drawing machines.
4.?Full-immersion lubrication guarantees the optimal wire-cooling effect and extends the service life of both the cones and drawing dies.
5.?It is equipped with first-class domestic brand low-voltage switches and brakes. (Note: “State 1st class brand” was a bit unclear. This assumes you meant a top-tier domestic brand. Adjust if incorrect.)
| Model: | 17-2DST |
| Usage: | Bare copper wire drawing |
| Inlet diameter: | 2XФ2.5-3.5mm |
| Outlet diameter: | 2XФ0.4-1.2mm |
| Quantity of drawing dies: | 17 |
| Slip ratio of main machine: | 20% |
| Slip ratio of last die: | 15% |
| Correction system: | Automatically control |
| Max. Drawing speed: | 30m/s |
| Using motor/ main motor: | 90KW AC |
| Dynamic control: | Double frequency converters control |
| Operation direction: | Right hand machine |
| (from Left to right) | |
| Colour: | As customer's need |
| Brand: | Liqiang or OEM |
| Voltage: | 380V or Customized |
| Brake: | Pneumatic brake |
