1.?The capstans are designed with a double-layer arrangement, which effectively saves space and optimizes the machine's footprint.
2.?The winding shaft utilizes dual-frequency conversion synchronous control, resulting in significant energy savings and enhanced operational efficiency.
3.?Thanks to the zero-slip pilot design, the machine achieves high productivity levels while consistently producing finished wires of excellent quality.
4.?The electrical control system is equipped with an automatic memory function. This ensures that during normal start-stop operations and restarts after shutdown, no manual assistance is required, and the machine can smoothly accelerate its operation.
| Model: | 24DW |
| Inlet diameter: | 0.6-1.2mm |
| Outlet diameter: | 0.1-0.3mm |
| Quantity of drawing dies: | 24 |
| Max. Drawing speed: | 2000m/min |
| Slip ratio of main machine: | 13% |
| Slip ratio of last die: | 8% |
| Using motor/ main motor: | 15KW |
| Usage: | Bare copper wire drawing |
| Correction system: | Automatically control |
| Voltage: | 380V or Customized |
| Colour: | As customer's need |
| Brand: | Liqiang or OEM |
| Brake: | Pneumatic brake |
| Operation direction: | Right hand machine |
