1.?Electrical Control Method: The spooling tension is pneumatically controlled and can be automatically adjusted. The machine is operated via a PLC + Touch-screen control system.
2.?Environmentally friendly paint is used, ensuring greater safety and peace of mind.
3.?The machine is equipped with imported electrical components, enabling fully automated production.
4.?High-precision gear transmission is adopted, featuring low noise and long-term service life.
| Model: | 17DBX |
| Inlet diameter: | 1.4-1.8mm |
| Outlet diameter: | 0.5-0.8mm |
| Quantity of drawing dies: | 17 |
| Slip ratio of main machine: | 13% |
| Slip ratio of last die: | 8% |
| Max. Drawing speed: | 360m/min |
| Using motor/ main motor: | 18.5kw |
| Usage: | Bare steel wire drawing |
| Correction system: | Automatically control |
| Annealing method: | DC three section annealing |
| Voltage: | 380V or Customized |
| Brake: | Pneumatic brake |
| Colour: | As customer's need |
| Brand: | Liqiang or OEM |
| Operation direction: | Right hand machine |
